Product Features
• Large LCD display with 48 hours of internal power backup capacitor
• LCD display alternates between time of day, volume remaining or days to regeneration, and tank in service (twin tank systems only)
• Compact turbine meter
• Downflow or upflow regeneration cycles
• Choose from 4 modes of operation: immediate meter regeneration, delayed meter regeneration, delayed time clock regeneration or day of week regeneration
• Continuous flow rate of 20 GPM
• Backwash capacity handles tanks up to 12" diameter for softener applications, 10" for filter applications
• Double backwash capability
| Valve Material | Fiber Reinforced Polymer | Inlet/Outlet | 3/4", 1", 1-1/4" |
| Cycles | 5 | Continuous | 7,92 GPM |
| Peak | 9 GPM | Cv | 5.0 |
| Max. Backwash | 7 GPM | Distributor Pilot | .8125" or 1.05" Pipe O.D. |
| Drain Line | 1/2" NPTF | Brine Valve 1600 | 1600 - 3/8" |
| Mounting Base | 1600 - 3/8" | Height from Top of Tank | 7-1/2" |
| Downflow/Upflow | Both | Adjustable Cycles | Yes |
| Water Softener | 6" - 12" Diameter | Filters | 6" - 10 " Diameter |
| Electrical Rating | 24 v, 50 Hz, 60 Hz | Estimated Shipping Weight Time Clock | 6 lbs |
| Estimated Shipping Weight Metered Valve | 7 lbs. | Pressure Hydrostatic | 300 psi |
| Pressure Working | 20 - 125 psi | Temperature Cold Water Valve | 34o - 110o F |
